Municipal wastewater - KOSTRA, 2014

Simultaneously, there is also a large remaining share of around 17 per cent where compliance is unknown due to lack of reporting of permits and/or corresponding discharges.

The purpose with treatment permits is to prevent unwanted effects on the natural environment that receives treated wastewater from the wastewater facilities. Treatment permits are issued by the authorities, and are adjusted to the receiving water recipient and its sensitivity to pollution. The strictest permits are therefore to be found in areas where pollution loads are already high.

This is the second year Statistics Norway is releasing statistics on compliance with treatment permits and the most common non-compliance is found in relation to phosphorous permits. This is however not surprising since many wastewater facilities have a permit for the discharge of phosphorous. Many facilities also have permits on mechanical treatment, but these facilities are normally smaller in size and less prone to non-compliance.

Akershus and Rogaland have the longest pipeline system

Estimations for 2014 show that there were around 36 500 kilometres of municipal sewage pipelines in the whole country (not including separate storm water pipelines), which equals approximately 90 per cent of the circumference of the earth at the equator. The sewage pipelines can be broken down into 7 500 kilometres of combined sewage and storm water and 29 000 kilometres of a separate sewage system.

In addition to the 36 500 kilometres of sewage systems, there are an additional 16 500 kilometres of separate storm water pipelines; in total around 53 000 kilometres of municipal wastewater pipelines in Norway.

The municipalities in the counties of Akershus and Rogaland have the longest wastewater pipeline systems, while Oslo and counties in Nordland have the largest share of combined sewer systems.

0.62 per cent of sewage system renewed

In 2014, 230 out of the 36 500 kilometres of the existing sewage pipeline system was renewed, representing 0.62 per cent. Installation of new sewage pipelines constitute 344 kilometres during the same time period, corresponding to 0.92 per cent of the existing sewage pipeline system. Thus, the rate of installation of new pipelines is significantly faster than renewal; a situation that has remained the same since 2002, when registrations started.

Unless renewal rates increase, aging sewage pipelines throughout the municipalities will be the unavoidable result. Even without new installations it will take more than 160 years to renew the whole pipeline system with the current renewal rate.

The age of the sewage pipeline system for the country as a whole has been estimated at around 28 years old (37 years when adjusted for pipelines laid down in an unknown period – constituting 17 per cent of the total length). Around 2.4 per cent of the municipal wastewater pipelines were installed before 1940, while 51 per cent were installed in 1980 or later.

Highest renewal rates in Oslo, Akershus and Østfold

Renewals tend to vary from one year to another. The key figure “Percentage of total sewage pipeline system renewed, 3-year moving average” will even out these cyclical variations.

For the period 2012-2014, Oslo and the municipalities in the counties of Akershus and Østfold saw the most renewals on average per year, with 1.54, 0.89 and 0.67 per cent respectively, while Nordland, Nord-Trøndelag and Sogn og Fjordane renewed the least, with 0.26, 0.29 and 0.29 per cent respectively.

For the country as a whole, the 3-year-average renewal totalled 0.54 per cent per year, thus slightly lower than the single 2014 estimate of 0.62 per cent.

In 2014, 43 per cent of 403 reporting municipalities (428 in total) reported that they had renewed at least part of the sewage pipeline system, 8 per cent specified zero renewal and the remainder did not respond to that particular question. Corresponding figures on installation of new pipelines were 47 and 21 per cent of the municipalities respectively. In addition to the 403 municipalities above, there are also 25 municipalities that didn’t submit the form (“missing respondents”).

Sewage entering places it doesn’t belong

An estimated 1 900 sewage overflows have taken place throughout the country in 2014. This corresponds to 52 sewage overflows per thousand kilometres of municipal pipeline system – a 10 per cent decrease compared to 2013. Sewage overflows may lead to wastewater flowing to the storm water pipeline system and out to recipients or causing damage to buildings or other types of infrastructure.

Furthermore, the municipalities have accepted liability to around 340 closed cases of basement flooding in 2014.

85 per cent of inhabitants connected to municipal wastewater facilities

For 2014, it has been estimated that slightly less than 85 per cent of inhabitants are connected to municipal wastewater facilities of 50 population equivalents (pe) or more. Private solutions are most common among wastewater facilities of less than 50 pe.

Income from fees and fee calculation basis almost equal

In 2014, the fee calculation basis was NOK 1 586 per inhabitant, and the income from fees was NOK 1 526 per inhabitant. This constitutes an increase of 9 and 2 per cent respectively compared to 2013.

Municipal costs in the wastewater sector are predominantly covered by fees paid by the users of the service. Regulations stipulate that fees in the municipal water and wastewater sector cannot exceed the municipality’s actual costs for providing that particular service (“self cost”). Accurately stipulating income from fees to cover the real calculation basis in a single year is complicated, thus the municipalities are allowed to decide on fee levels so that income from fees over a five-year period equal the fee calculation basis.

Throughout the last five years, income from fees has increased by 22 per cent, while the fee calculation basis has increased by 28 per cent. In 2014, the income from fees was 4 per cent less than the fee calculation basis, but overall, for the whole five-year-period 2010-14, the income from fees has on the other hand been around 2 per cent higher than the fee calculation basis.
